HEXING PE foam net is a flexible, elastic, tubular foam product manufactured from expanded polyethylene through a unique extrusion and molding process.
Our protective polyethylene foam net features a three-dimensional mesh structure that provides excellent cushioning and shock absorption while allowing air circulation. Unlike traditional packaging materials, our EPE foam net conforms perfectly to irregular shapes, ensuring comprehensive protection for individual items during handling and transportation. Made from non-toxic, recyclable materials, our elastic PE foam net is an eco-friendly alternative to plastic bubble wrap and other single-use packaging solutions for industrial and commercial clients.
Core Advantages
360-Degree Protection: The tubular mesh design wraps completely around products, protecting all surfaces from scratches, dents, and impacts.
Excellent Elasticity: Stretches up to 300% of its original size to fit various product shapes and sizes without tearing.
Breathable Structure: Allows air circulation, preventing moisture buildup and mold growth, especially for fresh produce.
Lightweight and Cost-Effective: Reduces shipping weight and costs compared to heavier packaging materials.
Reusable and Recyclable: Can be reused multiple times and is fully recyclable, reducing environmental impact.
Non-Abrasive: Soft surface will not scratch or damage delicate finishes on glass, metal, or plastic products.
Technical Specifications
Parameter
Standard Range
Customization Available
Diameter
20 mm – 200 mm
Yes, 10 mm – 300 mm
Thickness
2 mm – 10 mm
Yes, 1 mm – 15 mm
Length per Roll
100 m – 500 m
Yes, custom lengths
Density
20 kg/m³ – 45 kg/m³
Yes, 15 kg/m³ – 60 kg/m³
Elongation at Break
≥ 250%
Yes, high-elasticity grades
Tensile Strength
≥ 0.2 MPa
Yes, reinforced grades
Operating Temperature
-30°C × 70°C
Yes, temperature-resistant grades
Colors
White, Yellow, Green, Red
Yes, any custom color
Production Process
Our industrial PE foam net production process is optimized for efficiency and quality. Material mixing starts with virgin polyethylene resin blended with foaming agents and colorants in a high-speed mixer. The mixture is heated and extruded through a specialized annular die to form a continuous tube. The extruded tube expands rapidly as the foaming agent vaporizes, creating the characteristic cellular structure. The expanded tube is passed through a rotating cutter head that creates the uniform mesh pattern. The foam net is then cooled, stretched to the desired diameter, and wound onto rolls for packaging.
Applications
Fresh Produce Packaging: Protection for apples, pears, peaches, mangoes, and other fruits during transportation and storage.
Glass and Ceramic Products: Wrapping for bottles, jars, cups, vases, and other fragile glassware.
Metal Products: Protection for pipes, fittings, tools, and hardware from scratches and corrosion.
Cosmetics and Personal Care: Packaging for perfume bottles, skincare containers, and cosmetic jars.
Electronics: Protection for small electronic components, cables, and accessories.
Customization Services
We provide extensive customization options for our protective foam net. We offer custom inner diameter and thickness to fit your products perfectly. Custom mesh size and pattern options are available for different protection requirements. We can produce foam net in any custom color and add custom printing. Custom roll lengths and packaging options are available to streamline your production process. We also provide pre-cutting services into individual sleeves of specified lengths. Anti-static and UV-resistant formulations are available, along with food-grade certified options for direct contact with produce.
Why Choose HEXING
HEXING is a leading manufacturer of high-quality PE foam products with a proven track record of serving industrial and commercial clients across 30+ countries. Our advanced production lines are capable of producing 8,000 tons of PE foam net annually, ensuring reliable supply for both small and large-scale operations. We use only premium raw materials and implement strict quality control measures at every stage of production to guarantee consistent product performance. Our experienced engineering team works closely with clients to develop custom foam net solutions that optimize protection while minimizing costs. We also offer competitive pricing, flexible payment terms, and fast worldwide shipping.
FAQs
Is your PE foam net food-safe?
Yes, our food-grade PE foam net is made from 100% virgin polyethylene and complies with FDA and EU food contact regulations.
Can you print logos or text on the foam net?
Yes, we can print custom logos, text, or patterns on the foam net using non-toxic, water-based inks.
What is the shelf life of PE foam net?
When stored in a cool, dry place away from direct sunlight, our PE foam net has a shelf life of up to 2 years.
PE automatic cutting machine is mainly based on the requirements of PE foam sheet/board for fixed length, fixed width cutting, can work online or offline, cutting size is accurate. Products are suitable for electronic products, toys, fruits, valuable or fragile items packaging, also used for mattresses, children's crawling MATS, splicing MATS, etc.
This machine is a deeply processing equipment of EPE foam sheet/film products, mainly used for the tectorial surface of EPE foam sheet/film.The material can be PE film, plated Aluminium foll, plastic-coated paper, plastic-coated fabric and so on. Laminated foam sheet increases intensity,waterproof ,and can be printed character, picture,improving the products grade, widely used for the packing of box lining, life vest, wooden floor underlayer. Car havelock,Motor adumbral cushion,household appliance.high-top Pottery and so on.
EPE foam net machine is a kind of new soft packing material. Mainly used in the production of PE foam net, it is through extruder and mold production of different sizes of products. Products are mainly used in various fruits, red wine , flowers and various fragile products packaging.
EPE foam pipe is a kind of new-type foam material and it is widely used in the jacket of air conditioner, pipeline heat insulation, toy guardrail and recreation places etc. due to its high foam ratio, good elasticity and heat preservation.
EPE foam sheet machine is a single stage extruding and foaming equipment with large L/D. It takes polyethylene resin with low density as raw material. This production line is the most ideal physical PE forming unit in the world. It has continuons stable performance with high yield,wide range of foaming ratio,high automation and reliability, products have a wide range of applications. The foam sheet has the features of dampproof , shockproof, soundproof, heat preservation and good plasticity.
Fully automatic forming and cutting machine integrates forming, cutting and stacking (trimming) at the same time. It has the features of saving labor, improving efficient, lowing labor intensity and reducing production cost. It adopts PLC controller and touch screen to control the working program.
This production line adopts double-screw foam sheet extrusion technology . PSP foam sheet is a kind of new-type packing material with the features of heat preservation, safety,sanitation and good plasticity. It’s mainly used to make various types of food containers, such as lunch box, dinner trays, bowls etc by thermoforming. It’s also can be used to make advertisement board, industrial products packing and so on. It has stable performance, big capacity, high automation and yields quality products.
XPS foam board,n amed as polystyrene extrusion board(XPS for short) has a flawless closed-pore cell structrue. Its density,water absorption, coefficient of heat conducting and the coefficient of steam pervasion are all lower that those of other board heat preservasion materials and they have the charact eristics of strong intensity, light material, airtight, anticorrosion, aging resistance, low cost, etc. It has been widely used in the fields of heat insulation in the construction indusry,frost resistance of the highway,railway,airport,square and household fitment.It is generally acknowledged the best heat preservation material in the market at present.
Pe foam recycling machine is to put PE foam products into the extruder to melt, at the same time to release the gas in the product and filter the impurities in the product, and then through the die head extrusion drawing, cooling, cutting, drying, packaging, to ensure the quality of particles.
Ps foam recycling machine is to put Ps foam products into the extruder to melt, at the same time to release the gas in the product and filter the impurities in the product, and then through the die head extrusion drawing, cooling, cutting, drying, packaging, to ensure the quality of particles.
This machine is mainly used in thickening EPE Foam Sheet with air as medium of heat conducting, making use of high temperature air to melt EPE Foam Sheet each other, then pressed by the steel roller. This thickened sheet is used widely in construction material, packaging, shoes making, bags and suitcases industry etc. reason structure, high production efficiency, easy to operate etc. The working mode of the machine is divided into vertical and horizontal, mainly according to the product fit thickness to distinguish. Vertical equipment is suitable for low thickness products, horizontal equipment is suitable for large thickness products.
