HEXING PE foam sheet (also known as expanded polyethylene foam sheet) is a lightweight, closed-cell, non-crosslinked thermoplastic foam material produced through advanced extrusion and foaming technology.
Our high-density polyethylene foam sheet offers exceptional shock absorption, thermal insulation, and water resistance, making it an indispensable material for modern industrial packaging, construction, and manufacturing applications. Manufactured using 100% virgin polyethylene resin, our EPE foam sheet is non-toxic, odorless, and fully recyclable, aligning with global environmental protection standards. We provide custom PE foam sheet solutions in various thicknesses, densities, and colors to meet the diverse needs of industrial clients worldwide.
Core Advantages
Superior Shock Absorption: The unique cellular structure of our polyethylene foam sheet effectively disperses impact forces, providing reliable protection for fragile and high-value products during transportation and storage.
Excellent Thermal Insulation: Closed-cell design prevents heat transfer, making our insulated PE foam sheet ideal for temperature-sensitive product packaging and building insulation applications.
Water and Moisture Resistance: Non-absorbent material properties ensure consistent performance even in humid environments, eliminating the risk of product damage from moisture.
Lightweight and Flexible: Reduces overall shipping costs while remaining easy to cut, shape, and install according to specific requirements.
Chemical Resistance: Resists most acids, alkalis, and oils, ensuring long-term durability in harsh industrial environments.
Technical Specifications
Parameter
Standard Range
Customization Available
Thickness
0.5 mm – 50 mm
Yes, up to 100 mm
Width
1000 mm – 2000 mm
Yes, up to 3000 mm
Length
50 m – 200 m per roll
Yes, custom lengths
Density
18 kg/m³ – 60 kg/m³
Yes, 10 kg/m³ – 100 kg/m³
Tensile Strength
≥ 0.3 MPa
Yes, higher strength grades
Elongation at Break
≥ 120%
Yes, flexible grades
Operating Temperature
-40°C × 80°C
Yes, high-temperature resistant grades
Colors
White, Black
Yes, any custom color
Production Process
Our industrial PE foam sheet production follows a rigorous 5-step process to ensure consistent quality. Raw material preparation begins with virgin polyethylene resin mixed with food-grade foaming agents and additives in precise proportions. The mixture is then fed into a high-temperature extruder where it melts into a homogeneous liquid. The molten material is extruded through a specialized die, allowing controlled expansion to form the desired cellular structure. The foam sheet is cooled and passed through precision calenders to achieve uniform thickness and surface finish. Finally, the continuous sheet is cut to specified lengths, rolled, and packaged for shipment.
Applications
Industrial Packaging: Protection for electronics, appliances, furniture, and automotive parts during shipping.
Construction Industry: Thermal insulation for walls, roofs, and floors; soundproofing materials.
Sports and Leisure: Padding for helmets, protective gear, and sports equipment.
Medical Industry: Packaging for medical devices and sterile products.
Automotive Industry: Interior trim, door panels, and vibration damping components.
Customization Services
We offer comprehensive customization options for our packaging PE foam sheet. We provide custom thickness, width, and length to match your exact requirements. Custom density and hardness options are available for different application needs. We can produce sheets in any custom color and apply various surface treatments. Die-cutting services create specific shapes and sizes for your packaging needs. We also offer lamination with other materials including paper, film, and fabric. Anti-static and flame-retardant formulations are available for specialized industrial applications.
Why Choose HEXING
With over 15 years of experience in plastic foam manufacturing, HEXING is a trusted supplier for industrial clients globally. We operate state-of-the-art production facilities with an annual output capacity of 10,000 tons, ensuring timely delivery even for large orders. Our dedicated R&D team continuously innovates to develop high-performance foam solutions tailored to your specific needs. We adhere to strict quality control standards, with all products certified by ISO 9001, CE, and RoHS. Our professional technical support team provides pre-sales consultation and after-sales service to ensure your complete satisfaction.
FAQs
What is the minimum order quantity for custom PE foam sheets?
The minimum order quantity varies depending on the specifications, typically starting from 500 kg.
Can you provide samples for testing?
Yes, we offer free samples of standard sizes. Custom samples are available with a small fee, which will be refunded upon placing a formal order.
What is the lead time for production?
Standard orders are usually completed within 7-10 working days. Custom orders may take 10-15 working days depending on complexity.
PE automatic cutting machine is mainly based on the requirements of PE foam sheet/board for fixed length, fixed width cutting, can work online or offline, cutting size is accurate. Products are suitable for electronic products, toys, fruits, valuable or fragile items packaging, also used for mattresses, children's crawling MATS, splicing MATS, etc.
This machine is a deeply processing equipment of EPE foam sheet/film products, mainly used for the tectorial surface of EPE foam sheet/film.The material can be PE film, plated Aluminium foll, plastic-coated paper, plastic-coated fabric and so on. Laminated foam sheet increases intensity,waterproof ,and can be printed character, picture,improving the products grade, widely used for the packing of box lining, life vest, wooden floor underlayer. Car havelock,Motor adumbral cushion,household appliance.high-top Pottery and so on.
EPE foam net machine is a kind of new soft packing material. Mainly used in the production of PE foam net, it is through extruder and mold production of different sizes of products. Products are mainly used in various fruits, red wine , flowers and various fragile products packaging.
EPE foam pipe is a kind of new-type foam material and it is widely used in the jacket of air conditioner, pipeline heat insulation, toy guardrail and recreation places etc. due to its high foam ratio, good elasticity and heat preservation.
EPE foam sheet machine is a single stage extruding and foaming equipment with large L/D. It takes polyethylene resin with low density as raw material. This production line is the most ideal physical PE forming unit in the world. It has continuons stable performance with high yield,wide range of foaming ratio,high automation and reliability, products have a wide range of applications. The foam sheet has the features of dampproof , shockproof, soundproof, heat preservation and good plasticity.
Fully automatic forming and cutting machine integrates forming, cutting and stacking (trimming) at the same time. It has the features of saving labor, improving efficient, lowing labor intensity and reducing production cost. It adopts PLC controller and touch screen to control the working program.
This production line adopts double-screw foam sheet extrusion technology . PSP foam sheet is a kind of new-type packing material with the features of heat preservation, safety,sanitation and good plasticity. It’s mainly used to make various types of food containers, such as lunch box, dinner trays, bowls etc by thermoforming. It’s also can be used to make advertisement board, industrial products packing and so on. It has stable performance, big capacity, high automation and yields quality products.
XPS foam board,n amed as polystyrene extrusion board(XPS for short) has a flawless closed-pore cell structrue. Its density,water absorption, coefficient of heat conducting and the coefficient of steam pervasion are all lower that those of other board heat preservasion materials and they have the charact eristics of strong intensity, light material, airtight, anticorrosion, aging resistance, low cost, etc. It has been widely used in the fields of heat insulation in the construction indusry,frost resistance of the highway,railway,airport,square and household fitment.It is generally acknowledged the best heat preservation material in the market at present.
Pe foam recycling machine is to put PE foam products into the extruder to melt, at the same time to release the gas in the product and filter the impurities in the product, and then through the die head extrusion drawing, cooling, cutting, drying, packaging, to ensure the quality of particles.
Ps foam recycling machine is to put Ps foam products into the extruder to melt, at the same time to release the gas in the product and filter the impurities in the product, and then through the die head extrusion drawing, cooling, cutting, drying, packaging, to ensure the quality of particles.
This machine is mainly used in thickening EPE Foam Sheet with air as medium of heat conducting, making use of high temperature air to melt EPE Foam Sheet each other, then pressed by the steel roller. This thickened sheet is used widely in construction material, packaging, shoes making, bags and suitcases industry etc. reason structure, high production efficiency, easy to operate etc. The working mode of the machine is divided into vertical and horizontal, mainly according to the product fit thickness to distinguish. Vertical equipment is suitable for low thickness products, horizontal equipment is suitable for large thickness products.
